    • MASTER LEDspot LV - The ideal solution for spot lighting

      MAS LEDspotLV VLE D6.3-35W 830MR16 36DRN
      LED
      MAS LEDspotLV VLE D6.3-35W 830MR16 36DRN

      MAS LEDspotLV VLE D6.3-35W 830MR16 36DRN

      Order code: 49029700

      Full Product Code: 871869649029700

      Downloads

      Data sheet
      Size:715.0 kB

      See all downloads

    Videos

    [trigger to render Video Gallery]

    Images

    Specifications Show all

    General Information
    Cap base
    GU5.3  [ GU5.3]
    Nominal lifetime (nom.)
    25000 h
    Switching cycle
    50000X
    Technical type
    6.3-35W
    Light Technical
    Colour code
    830  [ CCT of 3000K]
    Beam Angle (Nom)
    36 °
    Light distribution
    36D  [ Medium beam]
    Luminous flux (nom.)
    395 lm
    Luminous flux (rated) (nom.)
    395 lm
    Luminous intensity (nom.)
    1000 cd
    Colour designation
    White (WH)
    Rated beam angle
    36 °
    Correlated colour temperature (nom.)
    3000 K
    Luminous efficacy (rated) (nom.)
    63 lm/W
    Colour consistency
    <6
    Color rendering index (nom.)
    80
    LLMF at end of nominal lifetime (nom.)
    70 %
    Luminous Flux In 90° Cone (Rated)
    395 lm
    Operating and Electrical
    Power (Rated) (Nom)
    6.3 W
    Lamp current (nom.)
    800 mA
    Wattage equivalent
    35 W
    Starting time (nom.)
    0.5 s
    Warm-up time to 60% light (nom.)
    instant full light
    Power factor (nom.)
    0.7
    Voltage (Nom)
    12 V
    Temperature
    T-Case maximum (nom.)
    100 °C
    Controls and Dimming
    Dimmable
    Yes
    Approval and Application
    Suitable for accent lighting
    Yes
    Energy efficiency label (EEL)
    A
    Energy Consumption kWh/1000 h
    7 kWh
    Product Data
    Full product code
    871869649029700
    Order product name
    MAS LEDspotLV VLE D6.3-35W 830MR16 36DRN
    EAN/UPC – product
    8718696490297
    Order code
    49029700
    Numerator – quantity per pack
    1
    Numerator – packs per outer box
    10
    Material no. (12NC)
    929001152202
    Net weight (piece)
    0.045 kg

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation Diagrams
    GU5.3
    GU5.3
