    • MASTER LEDspot PAR - The energy-saving alternative for lighting in public areas

      MASLEDspot D 8.5-75W 840CW PAR30S 25D
      LED
      MASLEDspot D 8.5-75W 840CW PAR30S 25D

      MASLEDspot D 8.5-75W 840CW PAR30S 25D

      Order code: 57807000

      Full Product Code: 871869657807000

      Downloads

      Data sheet
      Size:483.1 kB

      See all downloads

    Videos

    [trigger to render Video Gallery]

    Images

    Specifications Show all

    General Information
    Cap base
    E27  [ E27]
    Nominal lifetime (nom.)
    40000 h
    Switching cycle
    50000X
    Technical type
    8-75W
    Light Technical
    Colour code
    841  [ CCT of 4100K (841)]
    Beam Angle (Nom)
    25 °
    Light distribution
    25D  [ Medium beam]
    Luminous flux (nom.)
    840 lm
    Luminous flux (rated) (nom.)
    840 lm
    Luminous intensity (nom.)
    2800 cd
    Colour designation
    Cool White (CW)
    Rated beam angle
    25 °
    Correlated colour temperature (nom.)
    4000 K
    Luminous efficacy (rated) (nom.)
    94 lm/W
    Colour consistency
    <6
    Color rendering index (nom.)
    80
    LLMF at end of nominal lifetime (nom.)
    70 %
    Luminous Flux In 90° Cone (Rated)
    800 lm
    Operating and Electrical
    Input frequency
    50 to 60 Hz
    Power (Rated) (Nom)
    8.5 W
    Lamp current (nom.)
    38 mA
    Wattage equivalent
    75 W
    Starting time (nom.)
    0.5 s
    Warm-up time to 60% light (nom.)
    0.5 s
    Power factor (nom.)
    0.9
    Voltage (Nom)
    230 V
    Controls and Dimming
    Dimmable
    Yes
    Approval and Application
    Suitable for accent lighting
    Yes
    Energy efficiency label (EEL)
    A+
    Energy Consumption kWh/1000 h
    9 kWh
    Product Data
    Full product code
    871869657807000
    Order product name
    MASLEDspot D 8.5-75W 840CW PAR30S 25D
    EAN/UPC – product
    8718696578070
    Order code
    57807000
    Numerator – quantity per pack
    1
    Numerator – packs per outer box
    6
    Material no. (12NC)
    929001244202
    Net weight (piece)
    0.202 kg
