BCX416 10xLED-HB/NW-4000 100-277V 120

Specifications Show all

General Information

Number of light sources	10  [ 10 pcs]
Lamp family code	LED-HB  [ LED High Brightness]
Light source colour	Neutral white
Light source replaceable	No
Driver/power unit/transformer	PSR  [ Power supply unit regulating]
Driver included	Yes
Optic type	120  [ Beam angle 120°]
Luminaire light beam spread	125° x 120°
Protection class IEC	Safety class I (I)
Ready-to-install	-
Type description	No
CE mark	CE mark
CCC mark	-

Operating and Electrical

Input voltage	100 to 277 V
Input frequency	50 to 60 Hz

Controls and Dimming

Dimmable

Yes

Mechanical and Housing

Length

305 mm

Approval and Application

Ingress protection code

IP20  [ Finger-protected]

Initial Performance (IEC Compliant)

Init. Corr. colour temperature	4000 K
Init. colour rendering index	83

Application Conditions

Ambient temperature range	-20 to +50 °C
Maximum dimming level	10% (depends on dimmer, ELV)
Suitable for random switching	Yes (relates to presence/ movement detection and daylight harvesting)

Product Data

Full product code	871794388133899
Order product name	BCX416 10xLED-HB/NW-4000 100-277V 120
EAN/UPC – product	8717943881338
Order code	88133899
Numerator – quantity per pack	1
Numerator – packs per outer box	20
Material no. (12NC)	910503700992
Net weight (piece)	0.400 kg
