| Number of light sources | 1
[ 1 pc] |
| Lamp family code | LED-MP
[ LED Medium Power] |
| Beam angle of light source | -
°
|
| Light source colour | 840 neutral white
|
| Light source replaceable | No
|
| Number of gear units | 1 unit
|
| Gear | -
|
| Driver/power unit/transformer | PSU
[ Power supply unit] |
| Driver included | Yes
|
| Optic type | No
[ -] |
| Luminaire light beam spread | 135°
|
| Connection | Flying leads/wires
|
| Cable | -
|
| Protection class IEC | Safety class II (II)
|
| Glow-wire test | 650/30
[ Temperature 650 °C, duration 30 s] |
| Flammability mark | NO
[ -] |
| CE mark | CE mark
|
| ENEC mark | -
|
| Warranty period | 3 years
|
| Remarks | *-Per Lighting Europe guidance paper “Evaluating performance of LED based luminaires - January 2018”: statistically there is no relevant difference in lumen maintenance between B50 and for example B10. Therefore the median useful life (B50) value also represents the B10 value.
|
| Constant light output | No
|
| Number of products on MCB | 180
|
| RoHS mark | RoHS mark
|
| Input voltage | 220-240
V
|
| Input frequency | 50 to 60
Hz
|
| Inrush current | 2
A
|
| Inrush time | 3.2
ms
|
| Power factor (min.) | 0.8
|
| Dimmable | No
|
| Housing material | Polycarbonate
|
| Reflector material | -
|
| Optic material | -
|
| Optical cover/lens material | Polycarbonate
|
| Fixation material | Steel
|
| Optical cover/lens finish | Opal
|
| Overall length | 338
mm
|
| Overall width | 22
mm
|
| Overall height | 34
mm
|
| Ingress protection code | IP40
[ Wire-protected] |
| Mech. impact protection code | IK02
[ 0.2 J standard] |
| Initial luminous flux | 350
lm
|
| Luminous flux tolerance | +/-10%
|
| Initial LED luminaire efficacy | 88
lm/W
|
| Init. Corr. colour temperature | 4000
K
|
| Init. colour rendering index | ≥80
|
| Initial chromaticity | (0.39, 0.38) SDCM<5
|
| Initial input power | 4
W
|
| Power consumption tolerance | +/-10%
|
| Control gear failure rate at median useful life 50000 h | 7.5
%
|
| Lumen maintenance at median useful life* 50000 h | L65
|
| Ambient temperature range | 0 to +35 °C
|
| Performance ambient temperature Tq | 25 °C
|
| Suitable for random switching | No
|
| Full product code | 871869607249399
|
| Order product name | BN132C LED3S/840 PSU L300
|
| EAN/UPC – product | 8718696072493
|
| Order code | 07249399
|
| Numerator – quantity per pack | 1
|
| Numerator – packs per outer box | 24
|
| Material no. (12NC) | 910503910162
|
| Net weight (piece) | 0.120
kg
|
