    • FlexAccent G2 - Excellent light quality

      GD391B 3XLED10/830 PSU-E WB
      GD391B 3XLED10/830 PSU-E WB

      GD391B 3XLED10/830 PSU-E WB

      Order code: 01559331

      Full Product Code: 911401559331

      Downloads

      Leaflet
      Size:414.9 kB

      See all downloads

    Specifications Show all

    General Information
    Beam angle of light source
    - °
    Light source colour
    Premium white with CRI ≥80
    Number of gear units
    1 unit
    Driver/power unit/transformer
    ET  [ Electronic transformer]
    Driver included
    No
    Optic type
    No  [ -]
    Luminaire light beam spread
    34°
    Control interface
    -
    Connection
    CE  [ External connector]
    Protection class IEC
    Safety class II (II)
    Glow-wire test
    60030  [ Temperature 600 °C, duration 30 s]
    Flammability mark
    NO  [ -]
    CE mark
    CE mark
    ENEC mark
    -
    Warranty period
    3 years
    Constant light output
    No
    Number of products on MCB
    -
    RoHS mark
    RoHS mark
    Operating and Electrical
    Input voltage
    220 to 240 V
    Input frequency
    50 to 60 Hz
    Power factor (min.)
    0.9
    Controls and Dimming
    Dimmable
    No
    Mechanical and Housing
    Housing material
    Aluminum die-cast
    Reflector material
    -
    Optic material
    Polymethyl methacrylate
    Optical cover/lens material
    Polymethyl methacrylate
    Fixation material
    Aluminum
    Optical cover/lens finish
    Textured
    Overall height
    83 mm
    Overall diameter
    122.2 mm
    Approval and Application
    Ingress protection code
    IP20  [ Finger-protected]
    Mech. impact protection code
    IK03  [ 0.3 J]
    Initial Performance (IEC Compliant)
    Initial luminous flux
    3000 lm
    Luminous flux tolerance
    +/-10%
    Initial LED luminaire efficacy
    83.33 lm/W
    Init. Corr. colour temperature
    3000 K
    Init. colour rendering index
    >80
    Initial chromaticity
    SDCM<4
    Initial input power
    36 W
    Power consumption tolerance
    +/-10%
    Application Conditions
    Ambient temperature range
    -15 to +35 °C
    Maximum dimming level
    Not applicable
    Suitable for random switching
    No
    Product Data
    Full product code
    911401559331
    Order product name
    GD391B 3XLED10/830 PSU-E WB
    Order code
    01559331
    Numerator – quantity per pack
    1
    Numerator – packs per outer box
    1
    Material no. (12NC)
    911401559331
    Net weight (piece)
    1.899 kg
    Installation Diagrams
    GD391B 3XLED10 20 30
    GD391B 3XLED10 20 30
