| Beam angle of light source | -
°
|
| Light source colour | Premium white with CRI ≥80
|
| Number of gear units | 1 unit
|
| Driver/power unit/transformer | ET
[ Electronic transformer] |
| Driver included | No
|
| Optic type | No
[ -] |
| Luminaire light beam spread | 17°
|
| Control interface | -
|
| Connection | CE
[ External connector] |
| Protection class IEC | Safety class II (II)
|
| Glow-wire test | 60030
[ Temperature 600 °C, duration 30 s] |
| Flammability mark | NO
[ -] |
| CE mark | CE mark
|
| ENEC mark | -
|
| Warranty period | 3 years
|
| Constant light output | No
|
| Number of products on MCB | -
|
| RoHS mark | RoHS mark
|
| Input voltage | 220 to 240
V
|
| Input frequency | 50 to 60
Hz
|
| Power factor (min.) | 0.9
|
| Dimmable | No
|
| Housing material | Aluminum die-cast
|
| Reflector material | -
|
| Optic material | Polymethyl methacrylate
|
| Optical cover/lens material | Polymethyl methacrylate
|
| Fixation material | Aluminum
|
| Optical cover/lens finish | Textured
|
| Overall height | 231
mm
|
| Overall diameter | 90
mm
|
| Ingress protection code | IP20
[ Finger-protected] |
| Mech. impact protection code | IK03
[ 0.3 J] |
| Initial luminous flux | 3500
lm
|
| Luminous flux tolerance | +/-10%
|
| Initial LED luminaire efficacy | 76.09
lm/W
|
| Init. Corr. colour temperature | 3000
K
|
| Init. colour rendering index | >80
|
| Initial chromaticity | SDCM<4
|
| Initial input power | 46
W
|
| Power consumption tolerance | +/-10%
|
| Ambient temperature range | -15 to +35 °C
|
| Maximum dimming level | Not applicable
|
| Suitable for random switching | No
|
| Full product code | 911401844197
|
| Order product name | ST391T LED35/830 PSU-E NB 3C WH
|
| Order code | 01844197
|
| Numerator – quantity per pack | 1
|
| Numerator – packs per outer box | 1
|
| Material no. (12NC) | 911401844197
|
| Net weight (piece) | 1.199
kg
|
