RS391B LED35/840 PSU-E WB GM

Specifications Show all

General Information

Beam angle of light source	- °
Light source colour	840 neutral white
Number of gear units	1 unit
Driver/power unit/transformer	ET  [ Electronic transformer]
Driver included	No
Optic type	No  [ -]
Luminaire light beam spread	34°
Control interface	-
Connection	CE  [ External connector]
Protection class IEC	Safety class II (II)
Glow-wire test	60030  [ Temperature 600 °C, duration 30 s]
Flammability mark	NO  [ -]
CE mark	CE mark
ENEC mark	-
Warranty period	3 years
Constant light output	No
Number of products on MCB	-
RoHS mark	RoHS mark

Operating and Electrical

Input voltage	220 to 240 V
Input frequency	50 to 60 Hz
Power factor (min.)	0.9

Controls and Dimming

Dimmable

No

Mechanical and Housing

Housing material	Aluminum die-cast
Reflector material	-
Optic material	Polymethyl methacrylate
Optical cover/lens material	Polymethyl methacrylate
Fixation material	Aluminum
Optical cover/lens finish	Textured
Overall height	104 mm
Overall diameter	156 mm

Approval and Application

Ingress protection code	IP20  [ Finger-protected]
Mech. impact protection code	IK03  [ 0.3 J]

Initial Performance (IEC Compliant)

Initial luminous flux	3500 lm
Luminous flux tolerance	+/-10%
Initial LED luminaire efficacy	72.92 lm/W
Init. Corr. colour temperature	4000 K
Init. colour rendering index	>80
Initial chromaticity	SDCM<4
Initial input power	48 W
Power consumption tolerance	+/-10%

Application Conditions

Ambient temperature range	-15 to +35 °C
Maximum dimming level	Not applicable
Suitable for random switching	No

Product Data

Full product code	911401893499
Order product name	RS391B LED35/840 PSU-E WB GM
Order code	01893499
Numerator – quantity per pack	1
Numerator – packs per outer box	1
Material no. (12NC)	911401893499
Net weight (piece)	1.699 kg
