ESSENTIAL LEDtube 600mm 9W 865 T8 C W G

Specifications Show all

General Information

Cap base	G13  [ Medium Bi-Pin Fluorescent]
Main application	Industrial
Nominal lifetime (nom.)	30000 h
Switching cycle	50000X
B50L70	30000 h

Light Technical

Colour code	865  [ CCT of 6500K]
Beam Angle (Nom)	240 °
Luminous flux (nom.)	900 lm
Luminous flux (rated) (nom.)	900 lm
Correlated colour temperature (nom.)	6500 K
Colour consistency	<6
Color rendering index (nom.)	82
LLMF at end of nominal lifetime (nom.)	70 %

Operating and Electrical

Input frequency	50 to 60 Hz
Power (Rated) (Nom)	9 W
Lamp current (max.)	89 mA
Lamp current (min.)	38 mA
Starting time (nom.)	0.5 s
Warm-up time to 60% light (nom.)	instant full light s
Power factor (nom.)	0.92
Voltage (Nom)	100-240 V

Temperature

T ambient (max.)	45 °C
T ambient (min.)	-20 °C
T storage (max.)	65 °C
T storage (min.)	-40 °C
T-Case maximum (nom.)	70 °C

Controls and Dimming

Dimmable

No

Mechanical and Housing

Product length

600 mm

Approval and Application

Energy-saving product	Yes
Suitable for accent lighting	No
Approval marks	CE marking	UL certificate	RoHS compliance	KEMA Keur certificate
Energy Consumption kWh/1000 h	9 kWh

Product Data

Full product code	871869652789400
Order product name	ESSENTIAL LEDtube 600mm 9W 865 T8 C W G
EAN/UPC – product	8718696527894
Order code	52789400
Numerator – quantity per pack	1
Numerator – packs per outer box	10
Material no. (12NC)	929001194711
Net weight (piece)	0.120 kg
