| Application code | K302-A2-ITS
|
| Design | BC1-123
|
| Lamp type | SON/CDO
|
| Number of lamps | 1
piece/unit
|
| Input voltage | 230
V
|
| Input frequency | 50
Hz
|
| Power factor 100% load (nom.) | 0.85
|
| Mains voltage performance (AC) | -8%-+6%
|
| Mains voltage safety (AC) | -10%-+10%
|
| Input current with PF correction | 0.6
A
|
| Input current without PF Correction | 1.2
A
|
| Power factor without PF compensation (nom.) | 0.4
|
| Power losses (nom.) | 13.7
W
|
| Wire strip length | 6.0
mm
|
| Ballast contact wire cross section | 2.5
mm²
|
| Connector type | Screw
|
| Rated ballast-lamp power | 100 W
|
| Recommended ignitor | for SON/CDO/CDM lamps ignitor SKD 578 (913700655366) or series digital SUD40 (913700193591) only CDM
|
| T storage (max.) | 130
°C
|
| T storage (min.) | -30
°C
|
| T winding (max.) | 140
°C
|
| Delta-T normal conditions | 60
°C
|
| Active temperature protection | Yes
|
|
| Approval marks | CE marking
|
ENEC certificate
|
| Full product code | 871869674086600
|
| Order product name | BSN 100 K302-A2-ITS 230V 50Hz
|
| EAN/UPC – product | 8718696740866
|
| Order code | 74086600
|
| Numerator – quantity per pack | 1
|
| Numerator – packs per outer box | 6
|
| Material no. (12NC) | 913700752326
|
| Net weight (piece) | 1.400
kg
|
