| Light source colour | Cool white
|
| Number of gear units | 1 unit
|
| Driver/power unit/transformer | ET
[ Electronic transformer] |
| Driver included | No
|
| Optical cover/lens type | PCF
[ Polycarbonate bowl/cover frosted] |
| Control interface | -
|
| Connection | Flying leads/wires
|
| Cable | Cable 0.3 m without plug
|
| Protection class IEC | Safety class III (III)
|
| Flammability mark | F
[ For mounting on normally flammable surfaces] |
| CE mark | CE mark
|
| ENEC mark | -
|
| Warranty period | 3 years
|
| Constant light output | No
|
| RoHS mark | RoHS mark
|
| LED engine type | LED
|
| Dimmable | No
|
| Housing material | Aluminum die-cast
|
| Optic material | Polycarbonate
|
| Optical cover/lens material | Polycarbonate
|
| Fixation material | Stainless steel
|
| Optical cover/lens shape | Hemispherical flat
|
| Optical cover/lens finish | Frosted
|
| Overall height | 52
mm
|
| Overall diameter | 70
mm
|
| Mech. impact protection code | IK07
[ 2 J reinforced] |
| Initial luminous flux | 157
lm
|
| Initial LED luminaire efficacy | 65
lm/W
|
| Init. Corr. colour temperature | 5000
K
|
| Init. colour rendering index | 70
|
| Initial input power | 2.4
W
|
| Power consumption tolerance | +/-10%
|
| Ambient temperature range | -20 to +50 °C
|
| Maximum dimming level | Not applicable
|
| Full product code | 911401616403
|
| Order product name | BGS300 12xLED-HB-5000 24V D70
|
| Order code | 01616403
|
| Numerator – quantity per pack | 1
|
| Numerator – packs per outer box | 48
|
| Material no. (12NC) | 911401616403
|
| Net weight (piece) | 0.200
kg
|
