BCP463 19xLED-HB/RD 100-277V WH

Specifications Show all

General Information

Number of light sources	19  [ 19 pcs]
Lamp family code	LED-HB  [ LED High Brightness]
Light source colour	Red
Light source replaceable	No
Driver included	Yes
Optic type	8  [ Beam angle 8°]
Optical cover/lens type	GT  [ Tempered glass]
Luminaire light beam spread	8°
Protection class IEC	Safety class I (I)
CE mark	CE mark
UL mark	UL and cUL mark
Lifetime to 50% luminous flux	120000 h
Lifetime to 70% luminous flux	90000 h
FCC mark	FCC Class A
Angle	8°

Operating and Electrical

Input voltage	100 to 277 V
Input frequency	50 to 60 Hz

Controls and Dimming

Dimmable

Yes

Mechanical and Housing

Housing configuration

BV  [ Basic version]

Approval and Application

Ingress protection code

IP66  [ Dust penetration-protected, jet-proof]

Initial Performance (IEC Compliant)

Initial input power

30 W

Application Conditions

Ambient temperature range

-40 to +50 °C

Product Data

Full product code	871794379355699
Order product name	BCP463 19xLED-HB/RD 100-277V WH
EAN/UPC – product	8717943793556
Order code	79355699
Numerator – quantity per pack	1
Numerator – packs per outer box	2
Material no. (12NC)	910503702041
Net weight (piece)	5.000 kg
