| Light source colour | Red, green and blue (RGB)
|
| Number of gear units | 1 unit
|
| Driver/power unit/transformer | ET
[ Electronic transformer] |
| Driver included | No
|
| Optical cover/lens type | PC-S
[ Polycarbonate small] |
| Control interface | Dynamix DMX
|
| Connection | Flying leads/wires
|
| Cable | Cable 1.5 m without plug (C1K5)
|
| Protection class IEC | Safety class III (III)
|
| Flammability mark | F
[ For mounting on normally flammable surfaces] |
| CE mark | CE mark
|
| ENEC mark | -
|
| Warranty period | 3 years
|
| Outdoor optic type | Wide beam angle 50°
|
| Constant light output | No
|
| RoHS mark | RoHS mark
|
| LED engine type | LED
|
| Dimmable | Yes
|
| Housing material | Aluminum extruded
|
| Optic material | Polycarbonate
|
| Optical cover/lens material | Polycarbonate
|
| Fixation material | Aluminum
|
| Mounting device | MBA
[ Mounting bracket adjustable] |
| Optical cover/lens shape | Flat
|
| Optical cover/lens finish | Clear
|
| Overall length | 1190
mm
|
| Overall width | 63
mm
|
| Overall height | 59
mm
|
| Mech. impact protection code | IK06
[ 1 J] |
| Initial luminous flux | 2280
lm
|
| Initial LED luminaire efficacy | 45
lm/W
|
| Init. Corr. colour temperature | -
K
|
| Initial input power | 51
W
|
| Power consumption tolerance | +/-15%
|
| Ambient temperature range | -40 to +50 °C
|
| Maximum dimming level | 0% (digital)
|
| Full product code | 911401621403
|
| Order product name | BCP280 G2 36xLED-HP/RGB 24V L1190 WB
|
| Order code | 01621403
|
| Numerator – quantity per pack | 1
|
| Numerator – packs per outer box | 4
|
| Material no. (12NC) | 911401621403
|
| Net weight (piece) | 2.499
kg
|
