BCP280 G3 5LEDHP/3000 L300 24V A

Specifications Show all

General Information

Light source colour	Warm white
Number of gear units	1 unit
Driver/power unit/transformer	ET  [ Electronic transformer]
Driver included	No
Optical cover/lens type	ACC  [ Acrylic bowl/cover clear]
Connection	Flying leads/wires
Cable	Cable 1.0 m without plug (C1K)
Protection class IEC	Safety class III (III)
Flammability mark	F  [ For mounting on normally flammable surfaces]
Warranty period	3 years
Constant light output	No
RoHS mark	RoHS mark
LED engine type	LED

Operating and Electrical

Inrush current	30 A
Inrush time	0.03 ms

Controls and Dimming

Dimmable

No

Mechanical and Housing

Housing material	Aluminum extruded
Optic material	Acrylate
Optical cover/lens material	Acrylate
Mounting device	MBA  [ Mounting bracket adjustable]
Optical cover/lens shape	Conical
Optical cover/lens finish	Clear
Overall length	335 mm
Overall width	50 mm
Overall height	65 mm

Approval and Application

Mech. impact protection code

IK06  [ 1 J]

Initial Performance (IEC Compliant)

Initial luminous flux	890 lm
Initial LED luminaire efficacy	93 lm/W
Init. Corr. colour temperature	3000 K
Init. colour rendering index	70
Initial input power	9.6 W
Power consumption tolerance	+/-10%

Application Conditions

Ambient temperature range	-40 to +50 °C
Maximum dimming level	Not applicable

Product Data

Full product code	911401623504
Order product name	BCP280 G3 5LEDHP/3000 L300 24V A
Order code	01623504
Numerator – quantity per pack	1
Numerator – packs per outer box	8
Material no. (12NC)	911401623504
Net weight (piece)	0.549 kg
