| Number of light sources | 1
[ 1 pc] |
| Lamp family code | GRN55
[ LED GreenLine 5500 lm] |
| Light source colour | 740 neutral white
|
| Light source replaceable | Yes
|
| Number of gear units | 1 unit
|
| Driver/power unit/transformer | PSU
[ Power supply unit] |
| Driver included | Yes
|
| Optical cover/lens type | FG
[ Flat glass] |
| Luminaire light beam spread | 180°
|
| Embedded control | No
[ -] |
| Light regulation | -
|
| Electrical circuit protection | -
|
| Connection | No
[ -] |
| Cable | -
|
| Protection class IEC | Safety class II (II)
|
| Parts colour | Cover painted
|
| Coating | -
|
| Flammability mark | NO
[ -] |
| CE mark | CE mark
|
| ENEC mark | ENEC mark
|
| Warranty period | 5 years
|
| Outdoor optic type | Distribution medium
|
| Constant light output | No
|
| Number of products on MCB | 10
|
| RoHS mark | RoHS mark
|
| LED engine type | LED
|
| Product Family Code | BRP530
[ CitySoul gen2 Mini] |
| Upward light output ratio | 0.03
|
| Standard tilt angle post-top | 0°
|
| Standard tilt angle side entry | 0°
|
| Input voltage | 220 to 240
V
|
| Input frequency | 50 to 60
Hz
|
| Control signal voltage | 1-10 V DC
|
| Inrush current | 45
A
|
| Inrush time | 0.285
ms
|
| Power factor (min.) | 0.95
|
| Dimmable | No
|
| Housing material | Aluminum
|
| Reflector material | -
|
| Optic material | Polymethyl methacrylate
|
| Optical cover/lens material | Polymethyl methacrylate
|
| Fixation material | Aluminum
|
| Mounting device | 48/60S
[ Side-entry for diameter 48-60 mm] |
| Optical cover/lens shape | Convex lens
|
| Optical cover/lens finish | Mask (anti-glare)
|
| Overall length | 644
mm
|
| Overall width | 538
mm
|
| Overall height | 101
mm
|
| Effective projected area | 0.025
m²
|
| Ingress protection code | IP66
[ Dust penetration-protected, jet-proof] |
| Mech. impact protection code | IK08
[ 5 J vandal-protected] |
| Initial luminous flux | 4704
lm
|
| Luminous flux tolerance | +/-7%
|
| Initial LED luminaire efficacy | 145
lm/W
|
| Init. Corr. colour temperature | 4000
K
|
| Init. colour rendering index | >70
|
| Initial chromaticity | (0.380, 0.370) SDCM<5
|
| Initial input power | 32.5
W
|
| Power consumption tolerance | +/-11%
|
| Ambient temperature range | -40 to +50 °C
|
| Maximum dimming level | Not applicable
|
| Full product code | 871869661391700
|
| Order product name | BRP530 LED55/740 II DM FG CO GR
|
| EAN/UPC – product | 8718696613917
|
| Order code | 61391700
|
| Numerator – quantity per pack | 1
|
| Numerator – packs per outer box | 1
|
| Material no. (12NC) | 910505016933
|
| Net weight (piece) | 12.700
kg
|
