| Number of light sources | 1
[ 1 pc] |
| Lamp family code | SON-T
[ SON-T] |
| Lamp power | 70
W
|
| Kombipack | Lamp(s) included
|
| Compensation circuit | Capacitive
|
| Gear | CONV
[ Conventional] |
| Optical cover/lens type | GB
[ Glass bowl/cover] |
| Electrical circuit protection | -
|
| Cable | -
|
| Protection class IEC | Safety class II (II)
|
| Parts colour | -
|
| CE mark | CE mark
|
| ENEC mark | ENEC mark
|
| Outdoor optic type | Open CT-POT
|
| Coloured frame | -
|
| RAL colour | -
|
| Filter coil | -
|
| Product Family Code | SGS452
[ IRIDIUM] |
| Standard tilt angle post-top | 5°
|
| Standard tilt angle side entry | 5°
|
| Input voltage | 230
V
|
| Ignitor | SND
[ Digital semi-parallel] |
| Mounting device | 60/76
[ Spigot for diameter 60-76 mm] |
| Overall height | 219
mm
|
| Ingress protection code | IP66
[ Dust penetration-protected, jet-proof] |
| Mech. impact protection code | IK08
[ 5 J vandal-protected] |
| Full product code | 871155984325400
|
| Order product name | SGS452 SON-T70W K II OR GB GR SND
|
| EAN/UPC – product | 8711559843254
|
| Order code | 84325400
|
| Numerator – quantity per pack | 1
|
| Numerator – packs per outer box | 1
|
| Material no. (12NC) | 910502126918
|
| Net weight (piece) | 9.442
kg
|
