BCP418 48xLED-HB/4000 220-240V 10 CE CQC

Specifications Show all

General Information

Number of light sources	48  [ 48 pcs]
Lamp family code	LED-HB  [ LED High Brightness]
Light source replaceable	No
Driver included	Yes
Optical cover/lens type	FG  [ Flat glass]
Protection class IEC	Safety class I (I)
Type description	No
CE mark	CE mark
ENEC mark	ENEC mark
UL mark	-
CQC mark	CQC-mark
Lifetime to 70% luminous flux	50000 h
Outdoor optic type	Narrow beam angle 10°
PSE mark	No
RoHS mark	-
WEEE mark	-
Product Family Code	BCP418  [ VAYA FLOOD HP WHITE]

Light Technical

Standard tilt angle post-top	0°
Standard tilt angle side entry	0°

Operating and Electrical

Input voltage	220 to 240 V
Input frequency	50 to 60 Hz

Controls and Dimming

Dimmable

Yes

Mechanical and Housing

Housing material	Aluminum
Optical cover/lens material	Glass

Approval and Application

Ingress protection code	IP66  [ Dust penetration-protected, jet-proof]
Mech. impact protection code	IK06  [ 1 J]

Initial Performance (IEC Compliant)

Init. Corr. colour temperature	4000 K
Init. colour rendering index	80

Application Conditions

Ambient temperature range	-20 to +40 °C
Average ambient temperature	25 °C

Product Data

Full product code	871829163526099
Order product name	BCP418 48xLED-HB/4000 220-240V 10 CE CQC
EAN/UPC – product	8718291635260
Order code	63526099
Numerator – quantity per pack	1
Numerator – packs per outer box	2
Material no. (12NC)	910503703123
Net weight (piece)	7.600 kg
