BCP433 GN 100-240 10 CE CQC PSE

Specifications Show all

General Information

Lamp family code	LED-HB  [ LED High Brightness]
Light source colour	Green
Light source replaceable	No
Protection class IEC	Safety class I (I)
CE mark	CE mark
CQC mark	CQC-mark
Outdoor optic type	Narrow beam angle 10°
PSE mark	PSE mark
Product Family Code	BCP433  [ VAYA FLOOD LP G2 MONO]

Operating and Electrical

Input voltage	100 to 240 V
Input frequency	50 to 60 Hz

Controls and Dimming

Dimmable

Yes

Approval and Application

Ingress protection code	IP66  [ Dust penetration-protected, jet-proof]
Mech. impact protection code	IK05  [ 0.7 J]

Product Data

Full product code	871829164715799
Order product name	BCP433 GN 100-240 10 CE CQC PSE
EAN/UPC – product	8718291647157
Order code	64715799
Numerator – quantity per pack	1
Numerator – packs per outer box	4
Material no. (12NC)	912400133912
Net weight (piece)	2.670 kg
