BCP432 4000 100-240 10 CE CQC PSE

Specifications Show all

General Information

Lamp family code	LED-HB  [ LED High Brightness]
Light source colour	Neutral white
Light source replaceable	No
Driver included	Yes
Optical cover/lens type	GT  [ Tempered glass]
Luminaire light beam spread	10°
Protection class IEC	Safety class I (I)
CE mark	CE mark
CQC mark	CQC-mark
Outdoor optic type	Narrow beam angle 10°
PSE mark	PSE mark
Angle	10°
Product Family Code	BCP432  [ VAYA FLOOD LP G2 WHITE]

Operating and Electrical

Input voltage	100 to 240 V
Input frequency	50 to 60 Hz

Controls and Dimming

Dimmable

Yes

Mechanical and Housing

Housing material	Aluminum die-cast
Optic material	Glass
Optical cover/lens material	Tempered glass
Optical cover/lens shape	Flat
Optical cover/lens finish	Clear

Approval and Application

Ingress protection code	IP66  [ Dust penetration-protected, jet-proof]
Mech. impact protection code	IK06  [ 1 J]

Initial Performance (IEC Compliant)

Initial luminous flux	3797 lm
Initial luminous flux	3797 lm
Initial LED luminaire efficacy	61.8 lm/W
Init. Corr. colour temperature	4000 K

Over Time Performance (IEC Compliant)

Lumen Maintenance 70% at 25°C Calculated	36000
Lumen Maintenance 70% at 25°C Reported	36000
Lumen Maintenance 70% at 40°C Calculated	36000
Lumen Maintenance 70% at 40°C Reported	36000
Lumen Maintenance 80% at 25°C Reported	36000
Lumen Maintenance 80% at 40°C Reported	36000
Lumen Maintenance 90% at 25°C Reported	36000
Lumen Maintenance 90% at 40°C Reported	36000

Application Conditions

Ambient temperature range

-40 to +40 °C

Product Data

Full product code	871829164739399
Order product name	BCP432 4000 100-240 10 CE CQC PSE
EAN/UPC – product	8718291647393
Order code	64739399
Numerator – quantity per pack	1
Numerator – packs per outer box	4
Material no. (12NC)	912400133927
Net weight (piece)	2.770 kg
