    • StyliD – the best energy-efficient range for retail applications

      ST740S LED27S/830 PSU MB WH
      LED
      ST740S LED27S/830 PSU MB WH
      StyliD

      ST740S LED27S/830 PSU MB WH

      Order code: 17811600

      Full product code: 871869917811600

      Downloads

      Leaflet
      Size:344.1 kB
      Revit file
      Size:2.4 MB

      See all downloads

    Specifications Show all

    General Information
    Beam angle of light source
    120 °
    Light source colour
    830 warm white
    Light source replaceable
    No
    Number of gear units
    1 unit
    Driver/power unit/transformer
    PSU  [ Power supply unit]
    Driver included
    Yes
    Optic type
    MB  [ Medium beam]
    Luminaire light beam spread
    30°
    Connection
    PIP  [ Push-in connector and pull relief]
    Cable
    -
    Protection class IEC
    Safety class II (II)
    Glow-wire test
    650/30  [ Temperature 650 °C, duration 30 s]
    Flammability mark
    F  [ For mounting on normally flammable surfaces]
    CE mark
    CE mark
    ENEC mark
    ENEC mark
    Warranty period
    5 years
    Remarks
    *-Per Lighting Europe guidance paper “Evaluating performance of LED based luminaires - January 2018”: statistically there is no relevant difference in lumen maintenance between B50 and for example B10. Therefore the median useful life (B50) value also represents the B10 value.
    Constant light output
    No
    Number of products on MCB
    34
    RoHS mark
    RoHS mark
    Product Family Code
    ST740S  [ StylID Comp. Maxos fusion]
    Operating and Electrical
    Input voltage
    220 to 240 V
    Input frequency
    50 to 60 Hz
    Inrush current
    18 A
    Inrush time
    0.25 ms
    Power factor (min.)
    0.9
    Controls and Dimming
    Dimmable
    No
    Mechanical and Housing
    Housing material
    Metal/Plastic
    Reflector material
    Polycarbonate aluminum coated
    Optic material
    Polycarbonate
    Optical cover/lens material
    Polymethyl methacrylate
    Fixation material
    -
    Optical cover/lens finish
    Clear
    Overall length
    172 mm
    Overall width
    84 mm
    Overall height
    184 mm
    Approval and Application
    Ingress protection code
    IP20  [ Finger-protected]
    Mech. impact protection code
    IK02  [ 0.2 J standard]
    Initial Performance (IEC Compliant)
    Initial luminous flux
    2600 lm
    Luminous flux tolerance
    +/-10%
    Initial LED luminaire efficacy
    116 lm/W
    Init. Corr. colour temperature
    3000 K
    Init. colour rendering index
    ≥80
    Initial chromaticity
    (0.43, 0.40) SDCM <3
    Initial input power
    22.5 W
    Power consumption tolerance
    +/-10%
    Over Time Performance (IEC Compliant)
    Control gear failure rate at median useful life 50000 h
    5 %
    Lumen maintenance at median useful life* 50000 h
    L80
    Application Conditions
    Ambient temperature range
    +10 to +40 °C
    Performance ambient temperature Tq
    25 °C
    Suitable for random switching
    Yes (relates to presence/ movement detection and daylight harvesting)
    Product Data
    Full product code
    871869917811600
    Order product name
    ST740S LED27S/830 PSU MB WH
    EAN/UPC – product
    8718699178116
    Order code
    17811600
    Numerator – quantity per pack
    1
    Numerator – packs per outer box
    1
    Material no. (12NC)
    910500465021
    Net weight (piece)
    1.200 kg

    Eco passport - Our environmental product specifications overview

    Philips cares about the environment and society at large, and strongly supports eco-design of products.

    Installation diagrams
     STYLID COMPACT G3 TRACK - 830 warm white - Power supply unit - Medium beam - White
    STYLID COMPACT G3 TRACK - 830 warm white - Power supply unit - Medium beam - White
