| Number of light sources | 32
[ 32 pcs] |
| Lamp family code | ECO70
[ LED EconomyLine 7000 lm] |
| Lamp version | 3S
[ 3rd generation, screw fixation] |
| Light source colour | 830 warm white
|
| Light source replaceable | Yes
|
| Number of gear units | 1 unit
|
| Driver/power unit/transformer | PSR-CLO
[ Power supply unit regulating with constant light output] |
| Driver included | Yes
|
| Optical cover/lens type | FG
[ Flat glass] |
| Luminaire light beam spread | 150° x 62°
|
| Embedded control | CLO
[ Constant light output] |
| Electrical circuit protection | -
|
| Connection | W
[ Plug-in connector 3-pole Wieland/Adels compatible] |
| Cable | -
|
| Protection class IEC | Safety class I (I)
|
| Parts colour | All parts colored
|
| Coating | -
|
| Flammability mark | NO
[ -] |
| CE mark | CE mark
|
| ENEC mark | -
|
| Green flagship mark | Green Flagship
|
| Warranty period | 5 years
|
| Outdoor optic type | Distribution medium
|
| Coloured frame | -
|
| Photocell | No
[ -] |
| Remarks | *-Per Lighting Europe guidance paper “Evaluating performance of LED based luminaires - January 2018”: statistically there is no relevant difference in lumen maintenance between B50 and for example B10. Therefore the median useful life (B50) value also represents the B10 value.
|
| Constant light output | Yes
|
| Number of products on MCB | 11
|
| RoHS mark | -
|
| WEEE mark | -
|
| LED engine type | LED
|
| Product Family Code | BGP352
[ Iridium² LED Medium] |
| Upward light output ratio | 0
|
| Standard tilt angle post-top | 0°
|
| Standard tilt angle side entry | 0°
|
| Input voltage | 220 to 240
V
|
| Input frequency | 50 to 60
Hz
|
| Initial CLO power consumption | 54.67
W
|
| Average CLO power consumption | 62.835
W
|
| End CLO power consumption | 71
W
|
| Inrush current | 46
A
|
| Inrush time | 0.25
ms
|
| Power factor (min.) | 0.9
|
| Dimmable | No
|
| Housing material | Aluminum die-cast
|
| Reflector material | Acrylate
|
| Optic material | Polycarbonate
|
| Optical cover/lens material | Tempered glass
|
| Fixation material | Stainless steel
|
| Mounting device | 48/76
[ Universal for diameter 48-76 mm] |
| Optical cover/lens shape | Flat
|
| Optical cover/lens finish | Clear
|
| Torque | 25
|
| Overall length | 751
mm
|
| Overall width | 358
mm
|
| Overall height | 183
mm
|
| Effective projected area | 0.08
m²
|
| Ingress protection code | IP66
[ Dust penetration-protected, jet-proof] |
| Mech. impact protection code | IK08
[ 5 J vandal-protected] |
| Surge protection (common/differential) | Philips standard surge protection level
kV
|
| Initial luminous flux | 4839
lm
|
| Luminous flux tolerance | +/-7%
|
| Initial LED luminaire efficacy | 77
lm/W
|
| Init. Corr. colour temperature | 3000
K
|
| Init. colour rendering index | 80
|
| Initial chromaticity | (0.430, 0.300) SDCM <5
|
| Initial input power | 71
W
|
| Power consumption tolerance | +/-11%
|
| Control gear failure rate at median useful life 75000 h | 7.5
%
|
| Lumen maintenance at median useful life* 75000 h | L80
|
| Performance ambient temperature Tq | 25 °C
|
| Full product code | 871829142480200
|
| Order product name | BGP352 ECO70-3S/830 PSR-CLO DM AL GR CLO
|
| EAN/UPC – product | 8718291424802
|
| Order code | 42480200
|
| Numerator – quantity per pack | 1
|
| Numerator – packs per outer box | 1
|
| Material no. (12NC) | 910925439559
|
| Net weight (piece) | 13.175
kg
|
