| Number of light sources | 1
[ 1 pc] |
| Lamp family code | SON-TPP
[ SON-T PIA Plus] |
| Lamp power | 70
W
|
| Cap base | E27
[ E27] |
| Kombipack | Lamp(s) included
|
| Gear | CONV
[ Conventional] |
| Optical cover/lens type | PC
[ Polycarbonate bowl/cover] |
| Light regulation | -
|
| Protection class IEC | Safety class II (II)
|
| CE mark | CE mark
|
| ENEC mark | ENEC mark
|
| Outdoor optic type | Moveable reflector with Allen screw
|
| Photocell | No
[ -] |
| Product Family Code | SGS101
[ MALAGA] |
| Standard tilt angle post-top | 15°
|
| Standard tilt angle side entry | 15°
|
| Input voltage | 230 V (default) or 240
V
|
| Ignitor | SKD
[ Digital semi-parallel MK4] |
| Mounting device | 42/60
[ Universal for diameter 42-60 mm] |
| Ingress protection code | IP43/65
[ Wire-protected, rain/spray-proof; dust penetration-protected, jet-proof] |
| Mech. impact protection code | IK08
[ 5 J vandal-protected] |
| Full product code | 872790063460000
|
| Order product name | SGS101 SON-TPP70W K II MR-AS SKD 42/60
|
| EAN/UPC – product | 8727900634600
|
| Order code | 63460000
|
| Numerator – quantity per pack | 1
|
| Numerator – packs per outer box | 1
|
| Material no. (12NC) | 910925813012
|
| Net weight (piece) | 4.000
kg
|
