MASTER PL-S 11W/840/4P 1CT/5X10BOX

Specifications Show all

General Information

Cap base	2G7  [ 2G7]
Life to 50% failures preheat (nom.)	13000 h
LSF Preheat 2000 h Rated	99 %
LSF Preheat 4000 h Rated	98 %
LSF Preheat 6000 h Rated	97 %
LSF Preheat 8000 h Rated	92 %
LSF Preheat 16000 h Rated	30 %

Light Technical

Colour code	841  [ CCT of 4100K (841)]
Luminous flux (nom.)	900 lm
Luminous flux (rated) (nom.)	900 lm
Colour designation	Cool White (CW)
Chromaticity coordinate X (nom.)	381
Chromaticity coordinate Y (nom.)	379
Correlated colour temperature (nom.)	4000 K
Luminous efficacy (rated) (nom.)	82 lm/W
Color rendering index (nom.)	82
LLMF 2000 h Rated	95 %
LLMF 4000 h Rated	92 %
LLMF 6000 h Rated	90 %
LLMF 8000 h Rated	88 %
LLMF 12000 h Rated	86 %

Operating and Electrical

Power (Rated) (Nom)	11.6 W
Lamp current (nom.)	0.160 A

Temperature

Design temperature (nom.)

28 °C

Controls and Dimming

Dimmable

Yes

Mechanical and Housing

Cap base information

4P

Approval and Application

Energy efficiency label (EEL)	A
Mercury (Hg) content (nom.)	1.4 mg
Energy Consumption kWh/1000 h	13 kWh

Product Data

Full product code	871150026122970
Order product name	MASTER PL-S 11W/840/4P 1CT/5X10BOX
EAN/UPC – product	8711500261229
Order code	26122970
Numerator – quantity per pack	1
Numerator – packs per outer box	50
Material no. (12NC)	927936684011
Net weight (piece)	41.000 g
ILCOS Code	FSD-11/40/1B-E-2G7
