    • HF-Essential for TL5/TL-D

      HF-E 118 TL-D 220-240 50/60Hz
      HF-E 118 TL-D 220-240 50/60Hz
      HF-Essential for TL5/TL-D

      HF-E 118 TL-D 220-240 50/60Hz

      Downloads

      Data sheet
      Size:503.3 kB

      See all downloads

    Specifications Show all

    Operating and Electrical
    Input Frequency
    50 to 60 Hz
    Earth Leakage Current (Max)
    0.5 mA
    Inrush Current Width
    0.37 ms
    Inrush Current Peak (Max)
    15 A
    Line Frequency
    50 to 60 Hz
    Input Voltage
    220 to 240 V
    Approval and Application
    Ingress protection code
    IP20  [Finger-protected]
    Approval Marks
    CE marking
    C-Tick certificate
    CB Certificate
    KEMA Keur certificate
    RoHS Compliant
    Energy Efficiency Index
    A2
    Product Data
    Full product name
    HF-E 118 TL-D 220-240 50/60Hz
    Material number (12NC)
    913713038766
    Full product code
    871829166865700
    Numerator - Packs per outer box
    20
    Numerator - Quantity Per Pack
    1
    Order code
    913713038766
    Order product name
    HF-E 118 TL-D 220-240 50/60Hz
    EAN/UPC - Case
    8718291668664
    Mechanical and Housing
    Housing
    L 150x40x28
    General Information
    Number of Lamps
    1 piece/unit
    Wiring
    Connector Type Output Terminals
    Insert
    Connector Type Input Terminals
    Insert
    Temperature
    Ambient temperature range
    -10 °C to 50 °C
    T-Case Lifetime (Nom)
    75 °C
    T-Case Maximum (Max)
    75 °C
    Installation Diagrams
    HF-E 118 TL-D 220-240 50/60Hz
    HF-E 118 TL-D 220-240 50/60Hz
    GDWD_HFETLDTL_0001-Wiring diagram
    GDWD_HFETLDTL_0001-Wiring diagram
